Extreme Duty Equipment Protection

Composite Enclosures

Watertronics Composite Enclosures are engineered to deliver unparalleled protection for your equipment, combining 100% non-corrosive materials with superior sound attenuation and weatherproofing. Constructed from pultruded fiberglass, these enclosures offer exceptional strength and durability, ensuring your equipment is safeguarded against impacts, chemicals, and harsh environmental conditions.

The thoughtful open panel design guarantees complete accessibility for easy maintenance and upgrades. With the added benefit of temperature control capabilities, our Composite Enclosures are perfectly suited for a wide range of applications, including pump station houses, chiller units, chemical storage, and filtration skids. Designed for resilience and versatility, Watertronics Composite Enclosures are the ideal choice for protecting critical infrastructure in any setting.

DESIGN BENEFITS

RELIABLE
100% non-corrosive, maintenance-free composite material—not susceptible to rust, rot or insect infestation
RESILIANT
Superior impact resistant exterior
NONDISRUPTIVE
Sound attenuating—natural composite material provides average sound reduction of 11 db
READY-TO-GO
Arrives fully assembled and generally does not require a building permit
Retrofit Existing Equipment
New construction or retrofit for existing installations
Wind Rate for Hurricanes
Industry’s only all composite PE stamped wind-load hurricane rated enclosure

STANDARD FEATURES

Features

• Panel construction: 32 lb. density closed-cell fiberglass reinforced urethane foam board

• Enclosure coating: 40mil UV stable 2-part Polyurea top coat

• Stainless Steel hardware— including lockable door handles, lift-off hinges, and fasteners

• Thermostat-controlled fan

• LED interior lighting

• Floor drain

• 120V outlet

• Removable panels, doors and roof

• Cane bolt door panel kickstands

• Sandstone or Green enclosure color

• Delivered fully assembled

• 2 year warranty

Structure

Roof

The roofs of our Composite Equipment Enclosures are engineered for both performance and practicality. Manufactured from a lightweight 32 lb. density fiberglass reinforced urethane foam board, each panel and roof assembly is bonded with a structural adhesive system that enhances durability without adding unnecessary weight.

These removable roofs provide full, 360-degree serviceability, allowing for easy access and maintenance. The combination of these materials delivers an outstanding strength-to-weight ratio, forming a resilient backbone for the entire enclosure system.

Reinforcement

Our Composite Equipment Enclosures are built to withstand even the most challenging environments, including hurricane-prone areas. They feature PE stamped, wind-rated structural design options that ensure robustness and safety under extreme weather conditions.

The interior of each enclosure is constructed from a unique 32 lb. density closed-cell lightweight fiberglass reinforced urethane foam board, providing superior toughness and durability. This combination not only reinforces the structure but also offers enhanced protection for the equipment housed within.

Enclosure Coating

Each of our Composite Equipment Enclosures is finished with a 40mil UV stable 2-part Polyurea top coat, offering an exterior surface that excels in impact resistance and abrasion durability. This high-performance coating ensures that the enclosure maintains its integrity and appearance under various environmental conditions.

Standard color options include Sandstone and Green, with custom colors available to match specific design requirements. The coating’s non-absorbent, durable nature provides an excellent bonding surface while enhancing sound and thermal insulation. Additionally, the composite material used is impervious to rust, rot, and insect infestation, ensuring long-lasting protection and reduced maintenance.

Stainless Steel Hardware

Our Composite Enclosures feature robust stainless steel lift-off door hinges, designed to enhance functionality and ease of use. These durable hinges allow door panels to be completely removed, providing unmatched interior accessibility for maintenance and adjustments. The stainless steel construction ensures long-lasting performance and resistance to corrosion, making them ideal for various environments.

By facilitating easier access to the enclosure’s interior, these lift-off door hinges streamline operations and improve overall efficiency, ensuring that routine tasks can be performed quickly and effortlessly.

Complete Service Access

Our Composite Enclosures are engineered with a modular design that emphasizes complete serviceability. Featuring removable roofs and lift-off door panels, these enclosures allow for 360-degree access to the interior. This innovative construction ensures that every component within the enclosure is easily reachable, facilitating maintenance, repairs, and adjustments from any angle.

By providing full access to all sides, our modular design significantly enhances operational efficiency, reduces downtime, and simplifies routine service tasks. This comprehensive service area solution is ideal for applications where ease of maintenance and quick access are crucial.

Sound Attenuation (Standard)

Our Composite Enclosures are designed with sound attenuation in mind, ensuring a quieter operational environment. The standard enclosure offers an impressive average sound reduction of 11 decibels (dB), significantly lowering noise levels to create a more comfortable and efficient workspace.

This advanced sound attenuation feature not only enhances the working conditions for personnel but also minimizes noise pollution in surrounding areas. By integrating cutting-edge materials and engineering techniques, our enclosures deliver superior acoustic performance, making them an ideal choice for a variety of applications where noise control is paramount.

Additional Options

At Watertronics, we understand that every installation has unique requirements. That’s why we offer an array of additional options to customize your Composite Equipment Enclosures precisely to your needs. Enhance the functionality and adaptability of your enclosures with the following upgrades:

Acoustic Insulation: Opt for our acoustic insulation to significantly reduce noise output by up to 20 dB, making it ideal for installations in noise-sensitive environments such as residential areas or near hospitals.
Thermal Insulation: Improve energy efficiency with optional thermal insulation that boasts an R-value of 9.5, perfect for maintaining temperature control and reducing energy costs in extreme climates.
Exterior Lighting: Enhance the visibility and security around your enclosures with additional exterior lighting options, ensuring safety and accessibility during low-light conditions.
Service Disconnect Pull Box: Integrate a service disconnect pull box for added safety and convenience, allowing for quick and easy power shutdown during maintenance or emergencies.
Roof Hatch: Equip your enclosure with a roof hatch to facilitate easy access for maintenance or equipment upgrades, providing a practical solution for handling large or cumbersome components.
Custom Enclosure Color: Tailor the appearance of your enclosures with custom color options to meet aesthetic or regulatory requirements, ensuring your setup complements its surroundings or adheres to specific visual guidelines.
PE Stamped Wind-Load Rated Structural Design: For installations in hurricane-prone regions, opt for a PE stamped, wind-load rated structural design that meets stringent safety standards, ensuring durability and stability under extreme conditions.
Factory Skid Mounted to Watertronics Pump Station: Streamline installation and enhance portability with our enclosures factory skid-mounted directly to Watertronics Pump Stations, providing a comprehensive, ready-to-install solution.
UL-Listing with UL-Listed Watertronics Packaged Pump Station: Ensure the highest standards of safety and compliance with an enclosure that is UL-listed along with a UL-Listed Watertronics Packaged Pump Station, offering peace of mind through rigorous testing and certification.

APPLICATIONS

Pump Houses

Chiller Enclosures

Equipment Protection

Chemical Storage

Filter Skids

DELIVERY AND INSTALLATION

Composite Enclosures arrive onsite fully assembled to expedite installation and eliminate site downtime due to construction.
Building permits generally not required.
Arrives fully assembled – no onsite downtime or construction zones
Factory mounted to skid with Watertronics Pumps stations and UL-listed
