WATER DISTRICTS

Watertronics is uniquely qualified to partner with water districts as they strive to provide clean and reliable water to their customers with the least amount of operating cost possible. Our experience with very large agricultural projects, municipal infrastructure projects and custom turf irrigation projects provides us with 40 years of experience in custom, large pumping solution designs. Our comprehensive capabilities to support the project initial scoping, system design, construction and implementation means we are truly a one stop shop for this highly specialized market.

Water Districts Gallery

Large Vertical Turbine Intake

Location: Sudan

Features:

  • 50,000 gpm (11,356 m3/hr) VTV-800X4 electric Nile River Pump station which pumps water 5 km and transports water 8 km to a 40 acre (16 ha) reservoir
  • 50,000 gpm (11,356 m3/hr) HC-800X7 diesel powered inline booster feeding 43 pivots over 12 km (12,000 m)
  • 13 Cluster locations
  • Integrated Canal Gate supply 30,000 GPM (6,814 m3/hr) to primary Canal
  • Pivot pump stations along primary canal feeding 6 new pivots
  • Canal Lift station transferring water from primary to secondary canal
  • Pivot pump stations along secondary canal feeding 17 new pivots
  • Radio telemetry system that allows centralized monitoring of pumps, mainlines, reservoir, pivots and canal gate status.
  • Multi year project executed in 2 phases

Potable Water

Location: Navajo Gallup Water Supply Project (Cutter Lateral), NM

Features:

  • Two Systems
  • (4) 250 HP medium voltage potable booster pumps
  • 4452 GPM at 204 PSI

Effluent Reuse

Location: Australia

Features:

  • (5) 216 HP Horizontal Centrifugal pumps
  • (1) 20 HP Vertical Multistage
  • 11,666 GPM at 109 PSI
  • 415 Volt, 50 HZ
  • 1,500 micron filtration
  • Electronic butterfly valves
  • Magnetic flow meters

Clean Surface Water

Location: Hammett, Idaho

Features:

  • 3 pump stations with separate zones, control panels and discharge
  • Zone 1: (2) 150 HP, (1) 125 HP 6,400 GPM at 80 PSI
  • Zone 2: (1) 125 HP, 2824 GPM at 53 PSI
  • Zone 3: (2) 100 HP, 4786 GPM at 47 PSI
  • Horizontal Centrifugal pumps
  • Remote Telemetry
  • VFD on lead pump for each zone with harmonic filters
  • Pressure relief valves on Zone 1 and 3 only
  • Air conditioned control panels
